Description
- Type : Shaded Pole
- HP : 1/50
- Voltage : 115
- RPM : 1550/900
- Current (Amp) : 1.2/0.7
- Phase : 1
- Rotation : Clockwise Shaft End
- Frame : 3.3
- Enclosure : Open Air Over
- Speeds : 2
- Protector : Thermally Protected
- Ambient Temp : 40°C
- Service Factor : 1.00
- Shaft Dimensions : 0.313 in X 2.45 in
- Frequency : 60Hz
- Diameter : 3.3 in
- Frame Length : 2.57 in
- Bearings : Sleeve
- Features : Class B Insulation, 12" Leads with Quick Connect Terminal Housing, Extended Studs Shaft End, Open Shaft End End-Frame, Open Shell, Enclosed Opposite Shaft End End-Frame
- References: Loren Cook GC/GN 142/144, 615251
- Cross Reference: 7173-1580
