Description
- Type : Shaded Pole
- HP : 1/10
- Voltage : 115
- RPM : 1050
- Current (Amp) : 3.20
- Phase : 1
- Rotation : Clockwise Lead End
- Frame : 42
- Enclosure : Open
- Speeds : 5
- Protector : Automatic
- Ambient Temp : 40°C
- Service Factor : 1.00
- Shaft Dimensions : 10-11/16 in X 1/2 in X 10-11/16 in (Double Shaft)
- Frequency : 60Hz
- Diameter : 5.0 in
- Frame Length : 3.50 in
- Bearings : Sleeve
- Features: Class A Insulation, Resilient Base
- Cross References: A.O. Smith BDL6409 DBL6409, Dayton 4MA19, Emerson 2827, Fasco 7151-0058 7151-0067 7151-0126 7151-0130 7151-0134 7151-0172 7151-2179 7151-2222 7151-2426 7151-2683, Fasco Catalogue A2743 D289, Franklin 8725610161 AO6618A, General Electric 2089, MacMillan 6125-261/118, Rotom R2634, Universal Electric CA3E040 CA3E041 DA3B013 DA3B014 DA3B015 DA3B016 DA3D003 DA3D004 DA3D009 DA3D010 DA3D012 DA3D064 DA3D065 DA3D066 DA3D069 DA3D070 DA3D073 DA3D075 DA3D082 DA3D093 DA3D099 DA3D100 DA3D102 DA3D105 DA3D115 DA3D116 DA3D122 DA3D123 DA3D142 DA3D144 DA3D154 DA3D157 DA3D173 DA3E001 DA3E005 DA3E007 DA3E008 DA3E009 DA3E011 DA3E012 DA3E013 DA3E014 DA3E015 DA3E017 DA3E022 DA3E023 DA3E024 DA3E026 DA3E035 DA3E037 DA3E038 DA3E040 DA3E041 DA3E045 DA3E051 DA3E058 DA3E068 DA3E069 DA3E072 DA3E073 DA3E075 DA3E076 DA3E083 DA3E090 DA3E091 DA3E092 DA3E095 DA3E098 DA3E099 DA3E100 DA3E102 DA3E104 DA3E117 DA3E124 DA3E137 DA3E138 DA3E140 DA3E143 DA3E145 DA3E148 DA3E150 DA3E153 DA3E160 DA3E167 DA3E171 DA3E175 DA3E180 DA3E186 DA3E198 DA3E219 DA3E236 DA3E259 DA3E260 DA3E666 DA3F005 DA3F025 DA3F035 DA3F045 DA3F051 DA3F055 DA3F056 DA3F059 DA3F062 DA3F070 DA3F083 DA3F088 DA3F094 DA3F105 DA3G001 DA3G002 DA3G007 DA3G008 DA3G011 DA3G016 DA3G017 DA3G018 DA3G019 DA3G025 DA3G031 DA3G032 DA3G054 DA3G055 DA3G062 DA3G068 DA3G070 DA3G073 DA3G077 DA3G078 DA3G084 DA3G086 DA3G091 DA3G093 DA3G095 DA3G105 DA3G106 DA3G118 DA3G132 DB3D002 DB3D004 DB3D007 DB3D014 DB3D017 DB3D021 DB3E001 DB3E002 DB3F002 DB3F003 DB3F004 DB3F005 DB3F014 DB3G003 DE3D002 DE3D017 DE3D020 DE3D048 DE3D062 DE3D073 DE3D086 DE3D119 DE3D125 DE3D224 DE3D231 DE3D254 DE3D275, PEMS D289
